American Panel 10X20-O Walk-In Combination Cooler/Freezer (50/50 Split) 7'-6" H X 19'-3" W X 9'-8" D
Delivery to:
- Highly efficient cooling & freezing with separate 2-1/2 HP & 3/4 HP systems
- 50/50 split for optimal storage flexibility in cooler/freezer
- Outdoor unit designed with durable acrylume interior & exterior
- View More Details
Special Quote Item.
Price-match Guarantee
Price-match Guarantee
Our Price-Match Guarantee promises to match any lower price you find at approved competitors within 30 days. See terms.
Secure Shopping
Secure Shopping
Shop with confidence—our site is secured with SSL encryption, and we prioritize your data security and privacy. Learn more.
The American Panel 10X20-O Walk-In Combination Cooler/Freezer (50/50 Split) is a robust solution for businesses requiring both cooling and freezing capabilities. Its dimensions of 7'-6" H x 19'-3" W x 9'-8" D accommodate diverse storage needs. Designed for outdoor use, this unit features foamed-in-place 4" urethane floor panels in the freezer section, while the cooler section is floorless on a vinyl screed. The construction includes an acrylume interior and exterior, enhancing durability and resistance to environmental factors. The cooler operates with a 3/4 HP medium temperature hermetic pre-charged remote quick-connect R448 refrigeration system, maintaining 35°F, and is powered by a condensing unit at 208v/60/1-ph, 12.7 amps, and an evaporator at 208v/60/1-ph, 1 amp. The freezer section is equipped with a 2-1/2 HP low temperature system capable of reaching -10°F, with a condensing unit at 208v/60/1-ph, 21.7 amps, and an evaporator at 208v/60/1-ph, 1.4 amps fans, and 8.2 amps heaters. Additional features include a hinged door with camlift hinges, a dial thermometer, vapor-proof light, a cover, and winterization controls. The Heatcraft Quick Response Controller is standard, optimizing operation and efficiency. This combination unit is ideal for markets requiring reliable and efficient temperature-controlled storage solutions, such as food service industries.
Product Description
The American Panel 10X20-O Walk-In Combination Cooler/Freezer (50/50 Split) is a robust solution for businesses requiring both cooling and freezing capabilities. Its dimensions of 7'-6" H x 19'-3" W x 9'-8" D accommodate diverse storage needs. Designed for outdoor use, this unit features foamed-in-place 4" urethane floor panels in the freezer section, while the cooler section is floorless on a vinyl screed. The construction includes an acrylume interior and exterior, enhancing durability and resistance to environmental factors. The cooler operates with a 3/4 HP medium temperature hermetic pre-charged remote quick-connect R448 refrigeration system, maintaining 35°F, and is powered by a condensing unit at 208v/60/1-ph, 12.7 amps, and an evaporator at 208v/60/1-ph, 1 amp. The freezer section is equipped with a 2-1/2 HP low temperature system capable of reaching -10°F, with a condensing unit at 208v/60/1-ph, 21.7 amps, and an evaporator at 208v/60/1-ph, 1.4 amps fans, and 8.2 amps heaters. Additional features include a hinged door with camlift hinges, a dial thermometer, vapor-proof light, a cover, and winterization controls. The Heatcraft Quick Response Controller is standard, optimizing operation and efficiency. This combination unit is ideal for markets requiring reliable and efficient temperature-controlled storage solutions, such as food service industries.
Product information
| Manufacturer | American Panel Corporation |
|---|---|
| Model Number | 10X20-O |
| Manufacturer Part # | 10X20-O |
| Finish | Acrylume |
| Installation | Outdoor |
| Nominal long side | 20' |
| Nominal height | 7'-6" |
| Nominal short side | 10' |
| Floor | Floor/floorless |
| Height | 90" |
| Width | 231" |
| Depth | 116" |
| Weight | 2760 lbs |
Certifications
No certifications available
